Lenovo 5D10R41285 original TN display FHD (1920x1080) matt 60Hz

Product Info

Manufacturer

Lenovo

Item Number

5D10R41285

Sub-Partnumbers

5D10R41288, 5D10R41287, 5D10W69518, 5D11D96483, B156HTN06.1 H/W:3A F/W:1, N156HGA-EA3 C2, N156HGA-EA3 C1

Safety information

Sicherheits- & Herstellerkontakt-Informationen

Common data

Condition

New

Technical Data

Size

15.6 Zoll / 39.6 cm

Resolution

1920x1080 / FHD

Panel

TN

Surface

matt

Frame rate

60Hz

Backlight

LED

Length / Width

35.1 cm / 21.6 cm

Thickness

slimline

Brackets

no bracket

Display connection

Position of display connector

bottom right

Width of display connector

2.0 cm

Number of pins

30

Displayansteuerung

eDP

Category

Category

Displays

Usage

Laptop

Excerpt of suitable models for P/N 5D10R41285

Lenovo ThinkBook 15 IML (20RW) , Lenovo IdeaPad S145-15IKB (81VD/81XM) , Lenovo IdeaPad 3-15IGL05 (82BU) , Lenovo IdeaPad S340-15IIL (81WL) , Lenovo IdeaPad 3-15ARE05 (81W4) , Lenovo IdeaPad 3-15IGL05 (81WQ) , Lenovo IdeaPad L340-15IRH (81LK) , Lenovo ThinkBook 15 IML (20RW) , Lenovo IdeaPad S340-15IWL (81N8) , Lenovo V140-15IWL (81K6)

You've found this article over a part number. We'll check if it's the correct sparepart for your machine. To do this, please insert the manufacturer and the name of the model in the order comment.

How to identify my notebook model?
